Bàn trộn Dynacord CMS-600-3-MIG
Mã SKU: CMS6003MIG
Mã hàng : CMS-600-3-MIG
Bảo hành : 12 tháng
Tình trạng : Còn hàng
Xuất xứ: Mới 100%
Mã hàng : CMS-600-3-MIG
Bảo hành : 12 tháng
Tình trạng : Còn hàng
Xuất xứ: Mới 100%
Liên hệ
Số lượng
Tư vấn & Báo giá
Hướng dẫn mua hàng
Phương thức thanh toánI. Đặc điểm của bàn trộn Dynacord CMS-600-3-MIG:
Bàn trộn Dynacord CMS-600-3-MIG là Sản phẩm của Thương hiệu Dynacord thuộc dòng MIXER DYNACORD, được nhập khẩu và phân phối chính hãng bởi Thiết Bị Âm Thanh Sân Khấu tại Việt Nam
Tích hợp các tính năng toàn diện của bàn trộn Dynacord CMS-600-3-MIG như equalizer và các hiệu ứng khác. Trộn các hệ thống nhỏ gọn Bàn trộn Dynacord CMS-600-3-MIG là một mixer cung cấp chuyên nghiệp tối ưu hóa một tất cả trong giải pháp cơ bản cho bất kỳ ứng dụng.Mixer CMS console cài đặt nhanh chóng, dễ sử dụng. Có kết nối USB.
II. Thông số kĩ thuật của bàn trộn Dynacord CMS-600-3-MIG:
| Channels | 4 +2 + 2 |
| MIC/Line-Mono | 4 |
| MIC/Line-Mono / USB-Stereo (Super Channel) | 2 |
| Line L-R / CD-IN-Stereo | 2 |
| Specifications | |
|---|---|
| Auxiliarys (AUX, MON) | Pre/Post switchable, Pre |
| MIC GAIN (LINE -20 dB) | +10 to +60 dB |
| TRIM LINE/CD (Stereo) | -10 to +20 dB |
| THD, at 1 kHz, MBW = 80 kHz | |
| MIC input to Master A L/R outputs, +16 dBu, typical | < 0.005% |
| Frequency Response, -3 dB, ref. 1 kHz | |
| Any input to any Mixer output | 15 Hz to 70 kHz |
| Crosstalk, 1 kHz | |
| Channel to Channel | < -80 dB |
| Mute and Standby switch attenuation | > 100 dB |
| Fader and FX/AUX/MON-Send attenuation | > 85 dB |
| CMRR, MIC input, 1 kHz | > 80 dB |
| Input Sensitivity, all level controls in max. position | |
| MIC | -74 dBu (155 µV) |
| LINE (Mono) | -54 dBu (1.55 mV) |
| LINE (Stereo) | -34 dBu (15.5 mV) |
| CD (Stereo) | -34 dBu (15.5 mV) |
| Maximum Level, mixing desk | |
| MIC inputs | +12 dBu |
| Mono Line inputs | +31 dBu |
| Stereo Line inputs | +30 dBu |
| All other inputs | +22 dBu |
| All other outputs | +22 dBu |
| Input Impedances | |
| MIC | 2 kOhms |
| CD In | 10 kOhms |
| All other inputs | > 15 kOhms |
| Output Impedances | |
| Phones | 47 Ohms |
| All other outputs | 75 Ohms (unbalanced), 150 Ohms (balanced) |
| Equivalent Input Noise, MIC input, A-weighted, 150 ohms | -130 dBu |
| Noise, Channel inputs to Master A L/R outputs, A-weighted | |
| Master fader down | -100 dBu |
| Master fader 0 dB, Channel fader down | -92 dBu |
| Master fader 0 dB, Channel fader 0 dB, Channel gain unity | -82 dBu |
| Equalization | - |
| LO Shelving | ±15 dB / 60 Hz |
| MID Peaking | ±12 dB / 2.4 kHz |
| HI Shelving | ±15 dB / 12 kHz |
| Master EQ 9-band (63, 125, 250, 500, 1k, 2k, 4k, 6.3k, 12k Hz) | ±10 dB / Q = 1.5 to 2.5 |
| Filter | |
| LO-CUT, mono inputs | f = 80 Hz, 18 dB/oct. |
| Filter | |
| LO-CUT, mono inputs | f = 80 Hz, 18 dB/oct. |
| Display | 128 x 64 pixels, OLED |
| Effects | |
| Type | Dual stereo 24/48-bit multi effects processors |
| Effects presets | 100 Factory + 20 User, Tap-Delay |
| Remote control | Footswitch, MIDI |
| Digital Audio Interface | |
| Channels | 4 In / 4 Out |
| AD/DA Conversion | 24-bit |
| Sampling Rate | 44.1 / 48 / 88.2 / 96 kHz |
| PC Interface | USB2.0, Female Type B |
| MIDI Interface | 5-pin DIN connector, In / Out |
| Protection | |
| Mixer Outputs (Relay controlled) | AUX, MON, MASTER A L/R |
| Switching Mode Power Supply (µC controlled) | Mains Over/Undervoltage |
| Phantom Power, switchable | 48 V DC |
| Power Requirements (SMPS with auto range mains input) | 100 V to 240 V AC, 50 Hz to 60 Hz |
| Power Consumption, at 1/8 maximum output power, 4 Ohms | 35 W |
| Safety Class | I |
| Ambient Temperature Limits | +5 °C to +40 °C (40 °F to 105 °F) |
| Dimensions (W x H x D), mm | 416.9 x 108.6 x 347.8 Rack-mount (7.5 HE): 483.0 x 99.1 x 332.6 |
| Weight | |
| Net Weight | 5.8 kg |
| Shipping Weight | 7.8 kg |
| Warranty | 36 months |
| Optional Accessories | |
| RMK-600-3 (Rack Mount Kit for CMS 600-3) | F01U214881 (DC-RMK-CMS-3) |
| FS 11 (Footswitch with LED) | F01U100598 (DC-FS11) |
| Carrying Bag for CMS 600-3 | F01U259015 (DC-BAG-600CMS) |
