Mixer kèm công suất Dynacord PowerMate PM600-3-MIG

(0 đánh giá)

Mã SKU: PM6003MIG
Mã hàng : PM 600-3-MIG
Bảo hành : 12 tháng
Tình trạng : Còn hàng
Xuất xứ: Mới 100%

Liên hệ

Số lượng

Tư vấn & Báo giá

Hướng dẫn mua hàng

Phương thức thanh toán

I. Giới thiệu Mixer kèm công suất Dynacord PowerMate PM600-3-MIG:

Thương hiệu Dynacord Thương hiệu Dynacord thuộc dòng MIXER DYNACORD, được nhập khẩu và phân phối chính hãng bởi Thiết Bị Âm Thanh Sân Khấu tại Việt Nam

Tích hợp của giao diện điều khiển pha trộn, tăng âm và các thiết bị hiệu ứng trong một đơn vị nhỏ gọn và hiện đại đạt đến một tầm cao mới với PowerMate 600. Với 6 Mic / Line cũng như hai kênh Stereo / Line, hai tác dụng các thiết bị 24-bit mixable, một 7 band equalizer chủ và tích hợp tăng âm 2 x 300W, các PowerMate 600 là giải pháp đồng bộ để tuyệt đối cho vô số các ứng dụng, lý tưởng cho nhu cầu của ban nhạc nhỏ. Đối với các trường, các câu lạc bộ hoặc các tổ chức tương tự, các PowerMate là công cụ hoàn hảo cho một loạt các nhiệm vụ tăng cường âm thanh. An toàn và dễ dàng để sử dụng, nhanh chóng và đơn giản để thiết lập.

Mixer kèm công suất Dynacord PowerMate PM600-3-MIG

Mixer kèm công suất Dynacord PowerMate PM600-3-MIG số lượng đường vào: 4 đường vào mono, 4 đường vào stereo
Số đường vào micro (giắc XLR): 6
Số đường ra phụ (MON, FX, AUX): 1 Pre, 1 Post, 1 Pre/Post switchable
Công suất ra (1kHz, THD=1%): 2 x 1000W/ 4 Ohms
Công suất ra trung bình: 2 x 900W/ 4 Ohms (20Hz – 20kHz, THD < 0,5%)
2 đầu vào dòng âm thanh nổi
3 đường dẫn AUX
200 hiệu ứng âm thanh nổi có thể chỉnh sửa
4 x Giao diện USB I / O
Incl. Nắp vận chuyển bằng nhựa với Dynacord PowerMate 600-3
Loa đầu ra Twist
Âm thanh nổi 9 băng tần EQ
Bộ giá treo 19 "tùy chọn (RMK 600-3 - Điều Nr 285443 bắt buộc)

II. Thông số kỹ thuật của Mixer kèm công suất Dynacord PowerMate PM600-3-MIG

Specifications
Channels (Mono + Stereo)	4 + 4
Microphone Inputs (XLR)	6
Auxiliarys (MON, FX, AUX)	1 Pre, 1 Post, 1 Pre/Post switchable
Max. Single Channel Output Power, Dynamic-Headroom, IHF-A
into 2.66 Ohms	2 x 1600 W
into 4 Ohms	2 x 1250 W
into 8 Ohms	2 x 675 W
Max. Single Channel Output Power, Continuous, 1 kHz, THD = 1%
into 2.66 Ohms	2 x 1350 W
into 4 Ohms	2 x 1150 W
into 8 Ohms	2 x 650 W
Maximum Midband Output Power, 1 kHz, THD = 1%, Dual Channel
into 2.66 Ohms	2 x 1350 W
into 4 Ohms	2 x 1000 W
into 8 Ohms	2 x 600 W
Rated Output Power, 20 Hz to 20 kHz, THD < 0.5%, Single Channel
into 4 Ohms	2 x 900 W
into 8 Ohms	2 x 450 W
Maximum Output Voltage, of power amplifier, 1 kHz, no load	74 V_rms
THD, at 1 kHz, MBW = 80 kHz
MIC input to Master A L/R outputs, +16 dBu, typical	< 0.005%
POWER AMP INPUTS to Speaker L/R outputs	< 0.075%
DIM 30, power amplifier, 3.15 kHz, 15 kHz	< 0.05%
IMD-SMPTE, power amplifier, 60 Hz, 7 kHz	< 0.15%
Frequency Response, -3 dB, ref. 1 kHz
Any input to any Mixer output	15 Hz to 70 kHz
Any input to Speaker L/R output	20 Hz to 30 kHz
Crosstalk, 1 kHz
Amplifier L/R	< -85 dB
Channel to Channel	< -80 dB
Mute- and Standby-Switch attenuation	> 100 dB
Fader and FX/AUX/MON-Send attenuation	> 85 dB
CMRR, MIC input, 1 kHz	> 80 dB
Input Sensitivity, all level controls in max. position
MIC	-74 dBu (155 µV)
LINE (Mono)	-54 dBu (1.55 mV)
LINE (Stereo)	-34 dBu (15.5 mV)
CD (Stereo)	-34 dBu (15.5 mV)
POWER AMP INPUTS	+8 dBu (1.95 V)
Maximum Level, mixing desk
MIC inputs	+11 dBu
Mono Line inputs	+31 dBu
Stereo Line inputs	+31 dBu
All other inputs	+22 dBu
All other outputs	+22 dBu
Input Impedances
MIC	2 kOhms
CD In	10 kOhms
All other inputs	> 15 kOhms
Output Impedances
Phones	47 Ohms
All other outputs (balanced/unbalanced)	150 Ohms / 75 Ohms
Equivalent Input Noise, MIC input, A-weighted, 150 ohms	-130 dBu
Noise, Channel inputs to Master A L/R outputs, A-weighted	---
Master fader down	-100 dBu
Master fader 0 dB, Channel fader down	-92 dBu
Master fader 0 dB, Channel fader 0 dB, Channel gain unity	-82 dBu
Signal/Noise-Ratio, power amplifier, A-weighted, 4 Ohms	105 dB
Output Stage Topology, amplifier	Class D
Equalization
LO Shelving	±15 dB / 60 Hz
MID Peaking	±12 dB / 2.4 kHz
HI Shelving	±15 dB / 12 kHz
Master EQ 9-band (63, 125, 250, 500, 1k, 2k, 4k, 6.3k, 12k Hz)	±10 dB / Q = 1.5 to 2.5
Filter
LO-CUT, mono inputs	f = 80 Hz, 18 dB/oct., switchable
Speaker Processing	LPN, switchable
Effects	---
Type	2 x Stereo 24/48-bit multi effects processors
Effects presets	100 Factory + 20 User, Tap-Delay
Remote control	Footswitch, MIDI
Display	128 x 64 pixels, OLED
Digital Audio Interface
Channels	4 In / 4 Out
AD/DA Conversion	24-bit
Sampling Rate	44.1 / 48 / 88.2 / 96 kHz
PC Interface	USB2.0, Female Type B
Peak Display	6 dB before Clip
MIDI Interface	5-pin DIN connector, In / Out
Output Power Control (Speaker Protection)	Adjustable longterm RMS Limiter
Protection
Mixer Outputs, relay controlled	AUX, MON, MASTER A L/R
Amplifier	Audio Limiters, High Temperature, DC, HF, Short Circuit, Peak Current Limiters, Turn-on Delay, Back EMF
Switching Mode Power Supply (µC controlled)	Inrush Current Limiters, Mains Over/Undervoltage, Mains Over Current, High Temperature
Cooling	Continuous speed controlled Fans
Phantom Power, switchable	48 V DC
Power Requirements (SMPS with auto range mains input)	100 V to 240 V AC, 50 Hz to 60 Hz
Power Consumption, at 1/8 maximum output power, 4 Ohms	450 W
Safety Class	I
Ambient Temperature Limits	+5 °C to +40 °C (40 °F to 105 °F)
Dimensions (W x H x D), mm	With lid: 438.8 x 161.7 x 362.5 Rack-mount: 483 x 135.8 x 310.3 (7 HU)
Weight
Net Weight, without lid	9.0 kg
Net Weight, with lid	9.5 kg
Shipping Weight	12 kg
Warranty	36 months
Optional Accessories
Rack Mount Kit	F01U214880 (DC-RMK-600-3)
FS 11 (Footswitch with LED)	F01U100598 (DC-FS11)
Carrying bag	F01U259014 (DC-BAG-600PM)
